Product Features
UV Lasers(3W/5W) is featured with compact structure with extremely convenient installation and debugging. They have adopted the built-in laser diode technology to avoid the effect of fiber shaking on output laser. Besides, the beam quality is excellent enough to ensure the stability and reliability for mass production, which can meet the special manufacturing and processing demand in harsh industrial working condition.
Product Parameters
| No | ||
| 1 | Model | RL-UV 3W/5W10W |
| 2 | Laser wavelength | 355nm |
| 3 | Average power | > 3W@40kHz |
| 4 | Pulse Repetition Rate | 20kHz-200kHz |
| 5 | Spatial Mode | TEM00 (M2 1.2) |
| 6 | Pulse Width | 15ns@ 40kHz |
| 7 | Working Materials | Nd:YVO4 |
| 8 | Beam-pointing Stability | 25μrad |
| 9 | Beam Roundness | 90% |
| 10 | Beam diameter | less 8mm |
| 11 | Beam Divergence | less 2mrad |
| 12 | Pulse to pulse stability | less 3%rms |
| 13 | Ambient temperature | 18-35 degree |
| 14 | Cooling | Water cooling |
| 15 | Power consumption | 1600W |
| 16 | Classification | Class4 |
Advantages
German laser technology, independent research and development design, German 100-class clean room, full set of German production process.
UV laser source life over 5000 hours.
Laser source, control box, dual-load connector connection, separable, unlimited extension.
Excellent laser beam quality, M2<1.2. High beam pointing stability.
EZCAD / Marking Mate marking software, easy operate / powerful function.
Application
Cosmetics, pharmaceuticals, food and other polymer bottles’ surface. Marking effect is fine, clear and solid, which is better than the ink-jet printing and no pollution produced. Also used in marking and dicing flexible PCB board, drilling tiny hole or blind-hole on
silicon wafers, two-dimensional coding on LCD, glass container surface, metal surface
coating, plastic keys, electronic components, gifts, communication equipment, construction.
Packaging & Shipping
FAQ
Q1: I knew nothing about this machine, what kind of machine should I choose?
A1: Just tell us what you want to deal with, then we will give you suggestion and perfect solutions.
Q2: What should I do if I don’t know how to use it?
A2: We will send you a video and an English manual . If you still have some doubts, please do not hesitate to contact us.
Q3: If something goes wrong with this machine during warranty period, what should I do?
A3: We will supply free parts during warranty period if the machine had some problems.
Our services cover all industries and reach all parts of the world.
