High Light
IEC Handheld Laser Welding Machine
,2000W Handheld Laser Welding Machine
,1080nm Handheld Fiber Laser Welder
-
NameWater Cooling Handheld Laser Welding Machine For Kitchen Cabinets / Shelf
-
Laser Power1000W / 1500W / 2000W
-
Welding Thickness Range0.5~6mm
-
Application MaterialMetal Materials
-
Cooling TypeWater Cooling
-
Power Supply220V / 380V
-
Warranty1 Year
-
BrandHorizon Laser
-
Cable Length8m
-
Place Of OriginShenzhen / Suzhou
-
Welding Head TypeDouble Pendulum, Adjustable Spot
-
Key Selling Points6 Welding Modes, Suitable For Welding Of Different Products
-
Place of OriginChina
-
Brand NameHorizon laser
-
CertificationCE, IEC60825,IEC60204
-
Model NumberDPX-W1500
-
Minimum Order QuantityNegotiation
-
PriceNegotiation
-
Packaging DetailsWooden box: 1260*740*1480mm 300kg
-
Delivery Time3~5 days
-
Payment TermsT/T
-
Supply Ability100 sets per month
IEC 2000W Handheld Laser Welding Machine Water Cooling 1080nm
High Speed Handheld laser Welder Machine for Sheet Metal welding
Horizon Laser hand-held laser wwelding machine, uses latest generation laser generator. It's equipped with wobble weld head which is developed by ourselves. The machines appear to laser equipment industries, fills in the blank of hand-held welding. It has the advantages of simple operation, beautiful welding beam, fast welding speed and no consumables. Welding in thin stainless steel sheet, iron sheet, galvanized sheet and other metal materials can perfectly replace the traditional argon arc welding, electric welding and other processes. Handheld laser welding machine can be widely used in cabinets, kitchens, staircases, elevators, racks, ovens, stainless steel doors and windows guardrail, distribution boxes, stainless steel home and other industries complex and irregular welding process.
Parameters:
| Model | DPX-W1000 / DPX-W1500 / DPX-W2000 handheld laser welding machine |
| Laser Power |
1KW / 1.5KW / 2KW
|
| Laser Wave Length | 1080nm |
| Welding Speed | 0-120mm/s |
| Welding Gap | ≤1/5 of the thickness of sheet metal |
| Welding range | 0.5~6mm carbon steel,0.5~6mm stainless steel,0.5~4mm aluminium alloy,0.5~4mm brass |
| Fiber Length | Standard 8m |
| Cooling Mode | Water cooling |
| Electromechanical | 50HZ 220V / 380V optional |
Application industry:
Handheld Laser Welder Widely used in cabinet kitchen and bathroom, stair elevator, shelf, oven, tainless steel door, and window guardrall distribution box, stainless steel home.
Advantages of handheld laser welding machine:
Laser source and chiller are integrated in one machine, easy to move; Upper and lower layer design for heat source isolation,Ensuring working enviornment of laser source; easy to dismant and maintain
1. The weld seam is smooth and beautiful, reducing the subsequent grinding process, saving time and cost.
2. Wobble welding head compensates for the small disadvantage of laser welding spot, expands the tolerance rande of the machined pats and weld width, and obtains better weld formation.
3. The welding workpiece has no deformation, no welding, and the welding is firm.
4. Laser welding consumes less material and has a long life, laser welder hand held
5. Safer and more environmentally friendly, laser welding handheld type easy operation
6. The welding speed is 2-10 times faster than the traditional welding. One machine can save at least 2 welders a year.
7. The operation is simple
8. laser welding machine for sale
Our services cover all industries and reach all parts of the world.
