High Light
1080nm Laser Welding Machine
,1000W Laser Welding Machine
,Overlap Handheld Laser Welder
-
Laser Power1000W
-
UsageMetal Welding Cutting Cleaning
-
Cable Length15m
-
Welding Thickness Range0.8~2mm
-
Power Supply220V
-
Warranty1 Year
-
Place of OriginChina
-
Brand NameHorizon laser
-
CertificationCE, IEC60825, IEC60204
-
Model NumberDPX-W1000
-
Minimum Order QuantityNegotiation
-
PriceNegotiation
-
Packaging DetailsWooden box: 1260*740*1480mm 300kg
-
Delivery Time3~5 days
-
Payment TermsT/T
-
Supply Ability100 sets per month
1000W 1080nm Laser Welding Machine Water Cooling Overlap Handheld
Promotion for Handheld 1000W 1080nmLaser Welding Machine Welder
Handheld Fiber laser welding machine is a laser welding equipment which couples the high energy laser beams into the optical fiber, after long-distance transmission, then transformed into parallel lights through collimating mirror to be focused on the work piece to implement the welding. The welding methods include vertical welding, paraller welding, stitch welding and so on.
Parameters:
|
Model
|
DPX-W1000
|
|||
|
Laser Type
|
CW FIBER LASER
|
|||
|
Laser Wavelength
|
1070nm
|
|||
|
Laser Power
|
1000W | |||
|
Recommended welding thickness
|
0.5~2mm | |||
|
Spot size |
0.2~5mm | |||
|
Welding Speed Range
|
0~120mm/s
|
|||
|
Cooling System
|
Water Cooling
|
|||
|
Continous working time
|
24 Hours
|
|||
|
Environment temperature
|
0-35°C
|
|||
|
Voltage
|
220V/ 50 Hz or customized
|
|||
Advantages with Handheld Laser Welding Machine:
A. Handheld Laser Welding Machine is easy to handle and don't need the professional welder.
B. With 8-15m fiber wire, Can weld long-distance and large-area parts.
C. High quality and very stable: With a long lifespan to 100000 hours and free of maintance.
D. High efficiency: more than 5 times of the TIG welding with low energy consumption.
E. Various welding proceses: jam welding, seal welding, spot welding, stitch welding and overlap welding .
F:Inappreciable heat-affected zone, little deformation good-looking smoothly welding seam.
G. Little remedial work after welding, high-quality of welding line, precise control of positioning accuracy, small spot focus and automated welding
H: Low cost, no consumables, energy saving and enviroment protection.
I: Can support the different welding wires for stainless steel, Aluminum and Copper
SERVICE :
1. 1 year Guarantee for the whole machine.
2. 12 months Guarantee and free spare parts supply during this period.
3. 24 hours on line service
4. 3-7 days lead time
5. We will provide the Instruction Book, Operational manual and Training Video
6. Provide technical support for the whole lifetime on line
7. Shipping By air, DHL, Sea.
