20W 30W 50W Intelligent Fiber Laser Engraving Machine for Jewelry
Product Description
Horizon Laser develop and produce complete air cooling Fiber Optical Laser marking system in China. It is environmental friendly, low consumption, fully automatically and leading laser system. This creative laser system make the optical conversion rate up to 38%-50%, so only air cooling can meet the system requirements, this laser system is Small and compact size, Fiber output, can apply flexibly, and easy to make 3D processing system.
Our fiber laser marking machine Install backward reflecting isolator, which uses the particularity of wavelength and direction of laser, and the special structure inside the backward reflecting isolator, to block the laser reflected by work piece, in order to avoid the laser enter the laser oscillator again to damage the laser oscillator.
Rapid cache transmission control and selective elements greatly ensure long-time work continuously, to ensure the Production capability Control of ± 0.1C° High precision, perfect control board and optimal controlling system design carefully ensure the processing production rate. Quick speed, High impulse power, little electricity consumption, Low operation cost, No consumables.
2. Product Parameter (Specification)
| Laser power | 30w |
| Laser repetition rate | 20kHz-60kHz |
| Minimum line width | 0.012mm |
| Marking speed | ≤10000mm/s |
| Marking speed | ≤ 0.4mm (by materials) |
| Repeatability accuracy | ±0.001mm |
| Marking table | 480x200x460mm |
| Cooling mode | Fan cooling |
| Power supply | 220V/ single phase /50Hz/3A |
| Power | 400W (power saving) |
| file format | All font / font of WINDOWS operating system font library |
| operating system | Windows 32/64bit |
| Laser source dimension | 360*135*250mm |
| Net Weight | 42KG |
| Warranty | 2 Years |
| Delivery time | 7- 12 Work Days |
3. Application
The machine is widely applied in electronic component, the communication, the spare parts of automobiles and motorcycles, instrument and meter, aerospace, war products, hardware and machinery, measuring and cutting tools, sanitary equipment, medication, food and beverage, cosmetics, drugs packing, medical appliance, solar energy, handicraft and so on. It is suitable to mark on all kinds of metal and partial nonmetallic material.
4. FAQ
Q1. What's your advantage? Why choose you?
A: 1)We have the most professional techniques and team. More advantage in price
2) Great production capacity Sustainable Supply. According to customer requirements, We support the customized include package.
3) We use 100% new materials and the best production process, in consequence our defective rate is lower than 0.01%.
Q2. What's the Paying Method?
A: T/T would be better with quick transfer and few bank fees. LC could also be accept, but the procedure is complex and the fee is high.For large quantity,sea shipping can be provided.
Q3. Are you a factory or trading company?
A: We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
Q4. How can I get some samples?
A: We are honored to offer you samples. New clients are expected to pay for the courier cost, the samples are free for you, this charge will be deducted from the payment for formal order.
