FDA 0.01mm Portable 20w Fiber Laser Marking Machine

FDA 0.01mm Portable 20w Fiber Laser Marking Machine

Products - Laser Marking Machines
  • High Light

    0.01mm Portable 20w Fiber Laser Marking Machine

    ,

    FDA Portable 20w Fiber Laser Marking Machine

    ,

    12000mm portable laser etching machine

  • Application
    Laser Marking
  • Laser Type
    Fiber Laser
  • Certification
    CE
  • After-sales Service Provided
    Engineers Available To Service Machinery Overseas
  • Warranty Period
    1 Years
  • Place Of Origin
    Shenzhen, China
  • Power(W)
    20W/30W/50W
  • Brand Name
    Horizon Laser
  • Working Accuracy
    0.01mm
  • Place of Origin
    China
  • Brand Name
    Horizon laser
  • Certification
    CE
  • Model Number
    DPX-P20
  • Minimum Order Quantity
    1
  • Price
    USD
  • Packaging Details
    Wooden box
  • Delivery Time
    3~5 days
  • Payment Terms
    T/T
  • Supply Ability
    100 sets per month

FDA 0.01mm Portable 20w Fiber Laser Marking Machine

  • FDA 0.01mm Portable 20w Fiber Laser Marking Machine
  • FDA 0.01mm Portable 20w Fiber Laser Marking Machine
  • FDA 0.01mm Portable 20w Fiber Laser Marking Machine
Get Price Contact Now



20W high quality hot sale portable fiber laser marking machine for LED lights



Products Description:



Fiber laser marking was specially developed for industrial marking. The robust design with maintenance-free laser source guarantees constantly precise marking on the workpiece. This kind od fiber laser marking machine due to its laser beam is thin, the processing material consumption is small, and the processing heat affected area is small, so its your best choice.



20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights 0T





Main features for this 20W high quality hot sale portable fiber laser marking machine



1. Optical Fiber Laser, environment friendly, easy maintenance.
2. The laser life can be up to 100000 hours.
3. Small volume and weight, less than 40KGS.
4. Runs without consumable spare parts, no need maintenance, great for continuous working.
5. User-friendly controller and software make operation easier.
6. Compact, lightweight, simple interface, flexible and adjustable processing direction.
7. The master switch, red light switch and galvanometer switch.

8. High-speed scanning galvanometer guarantee high marking speed and high precision.

9. High precision scale.



Technical Parameters:



Product Fiber Laser Marking Machine
Fiber Laser Brand Standard: MAX
Fiber Laser Lifetime 100,000 hours
Fiber Laser Power 20W, 30W, 50W
Beam Quality M2≤1.2
Max. Marking Speed 12000mm/s
Laser Wavelength 1064nm
Marking Area Standard: 110mm*110mm
Optional: 70mm*70mm, 150mm*150mm, 200mm*200mm, 300mm*300mm
High-speed Galvanometer Yes
Lens F-Theta Lens
Fiber Laser Repetition Frequency 20KHz-80KHz
Minimum Character 0.05mm
Marking Depth ≤5mm
Repeated Accuracy ±0.001mm
Minimum Linewidth 0.01mm
Positioning accuracy 0.01mm
Repeatability 0.01mm
Volt 110V, 220V, or according to your request
Cooling Mode Air Cooling
Graphic Format Supported PLT, DXF, DXP, AI, GIF, TGA, PNG, TIF, TIFF, DST, DWG, LAS, SDT,BMP,JPG,JPGE ,etc
Software Supported CORELDRAW, AUTOCAD, PHOTOSHOP, etc
System Supported Windows, MAC OS
Operating Ambient Temperature 5°C-45°C
Marterial Supported Metal and Some Non-metal
Marking Software EZCAD
Desktop Computer Yes
Training Videos, User Manua Yes
Warranty 2 years
Fiber Test Results Yes
Certificates FDA, CE, ISO,RoHS, EUT, FC,CCC,PSE,IC
USB 2.0 Compatible YES
Size (L*W*H) 720mm*210mm*510mm
Weight 40KG
Optional Laptop, Rotary Device
Packing Wooden case





Marking samples:



FDA 0.01mm Portable 20w Fiber Laser Marking Machine 1
