New CNC Handheld fiber laser welder 1000W 1500W 2000W
Fiber Handheld Laser Welder or fiber handheld laser welding machine features an excellent accuracy and high power density of the laser beam, which is focused on a small area through an optical system.
It is the best portable laser welder for aluminum letters and other metal alloys thanks to its double wobble laser welding gun. That is to say, the welded parts form a localized heated area with a high concentration of energy in a very short time, so the fabrication material is melted. It creates a solid welding point, then the two pieces are joined together.
The handheld fiber laser welder machine adopts an integrated design with a small footprint, but a nice structure and a high precision beam mode. It boasts of a stable performance because of its continuous power and high quality parts. As a result, the handheld laser welder provides a fast welding speed, a wide welding range and a longer service life.
Parameters:
| Laser Power | 1000W / 1500W / 2000W |
| Center Wavelength | 1070+-5nm |
| Out Power Stability | 2% |
| Laser Frequency | 50Hz-5KHz |
| Adjustable Power Range | 5-95% |
| Beam Quality | 1.1 |
| Optimal Operating Environment Temperature | 10-35 ° C |
| Humidity | 20% -80% |
| Electricity Demand | AC220V |
| Output Fiber Length | 10 |
| Cooling Method | Water Cooling |
| Cooling Water Temperature | 20-25 ° C |
|
1kw welding ability
|
|||
|
No.
|
Material
|
Depth of fusion
|
Penetration thickness
|
|
1
|
Stainless Steel
|
≤4mm
|
≤3mm
|
|
2
|
Mild steel/Iron
|
≤4mm
|
≤3mm
|
|
3
|
Galvanized sheet
|
≤3mm
|
≤2mm
|
|
4
|
Aluminum/brass
|
≤2mm
|
≤1mm
|
|
1.5kw welding ability
|
|||
|
No.
|
Material
|
Depth of fusion
|
Penetration thickness
|
|
1
|
Stainless Steel
|
≤5mm
|
≤4mm
|
|
2
|
Mild steel/Iron
|
≤5mm
|
≤4mm
|
|
3
|
Galvanized sheet
|
≤4mm
|
≤3mm
|
|
4
|
Aluminum/brass
|
≤3mm
|
≤2mm
|
|
2kw welding ability
|
|||
|
No.
|
Material
|
Depth of fusion
|
Penetration thickness
|
|
1
|
Stainless Steel
|
≤6mm
|
≤5mm
|
|
2
|
Mild steel/Iron
|
≤6mm
|
≤5mm
|
|
3
|
Galvanized sheet
|
≤5mm
|
≤4mm
|
|
4
|
Aluminum/brass
|
≤4mm
|
≤3mm
|
Applications:
SERVICE :
1.The company who initially provide 1 years warranty in the world,
2.24-hour full after sales service.
3.All finished machine we delivered are 100% strictly tested by our QC department and engineering department.
4.OEM Service Customized and OEM orders are welcome due to our abundant experiences. All the OEM services are free.
Our services cover all industries and reach all parts of the world.
