1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel

1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel

Products - Fiber Laser Welder
  • Highlight

    1500W Fiber Laser Welder

    ,

    15m Fiber Laser Welder

    ,

    1500W Handheld Laser Welding Machine For Stainless Steel

  • Name
    1500W Handheld Laser Welder
  • Laser Power
    1500W
  • Welding Thickness Range
    0.5~4mm
  • Application Material
    Metal Materials
  • Usage
    Metal Welding
  • Warranty
    1 Year
  • Cable Length
    15m
  • Place Of Origin
    Shenzhen
  • Welding Head Type
    Double Pendulum, Adjustable Spot
  • Key Selling Points
    6 Welding Modes, Suitable For Welding Of Different Products
  • Place of Origin
    China
  • Brand Name
    Horizon laser
  • Certification
    CE, IEC60825,IEC60204
  • Model Number
    DPX-W1500
  • Minimum Order Quantity
    Negotiation
  • Price
    Negotiation
  • Packaging Details
    Wooden box: 1260*740*1480mm 300kg
  • Delivery Time
    3~5 days
  • Payment Terms
    T/T
  • Supply Ability
    100 sets per month

1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel

  • 1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel
  • 1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel
  • 1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel
  • 1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel
  • 1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel
Get Price Contact Now

1500W handheld laser welder for stainless steel iron aluminum copper brass



Product Description:

handheld laser welder, a good substitute of traditional welding.
All-In-One handheld fiber laser welder includes CW/pulsed output laser beam. Ideal for stainless sheet, iron sheet, galvanized sheet as well as aluminum sheet welding. It is a good substitution of the traditional electric welding, argon arc welding, and other processes.
Portable design for lap welding, edge welding, angle welding, tailoring welding, fillet welding, etc.



Parameters:



Model
 DPX-W1500
Laser Type
CW FIBER LASER
Laser Wavelength
1070nm
Laser  Power
 1500W
Recommended welding thickness
  0.5~4mm

 Spot size


  0.2~5mm
Welding Speed Range
0~120mm/s
Cooling System
Water Cooling
Continous working time
24 Hours
Environment temperature
0-35°C
Voltage
 220V/ 50 Hz or customized



Applications:

1500W Fiber Laser Welder , Handheld Laser Welding Machine For Stainless Steel 0

Advantages with Handheld Laser Welding Machine:

A. Handheld Laser Welding Machine is easy to handle and don't need the professional welder.
B. With 8-15m fiber wire, Can weld long-distance and large-area parts.
C. High quality and very stable: With a long lifespan to 100000 hours and free of maintance.
D. High efficiency: more than 5 times of the TIG welding with low energy consumption.
E. Various welding proceses: jam welding, seal welding, spot welding, stitch welding and overlap welding .
F:Inappreciable heat-affected zone, little deformation good-looking smoothly welding seam.
G. Little remedial work after welding, high-quality of welding line, precise control of positioning accuracy, small spot focus and automated welding
H: Low cost, no consumables, energy saving and enviroment protection.
I: Can support the different welding wires for stainless steel, Aluminum and Copper


FAQ



Q1. How to select the suitable machine?
Tell us your material, detail requirements by words, pictures or video.
We will recommend you the suitable model with the reasonable price.

Q2. How to install and use it?
We provide the instruction Book, Operational manual and Training Video.
We also can provide the training on line by free.

Q3. How to do it if we meet the issue during the operation?
You can send the wrong information to us by mail, we can help us solve it by mail.
phone, or video communication.

Q4. If we want to learn how to operate the machine, Can you provide it?
Yes, we can. We can provide the on line training by video. We also provide free training
course in our company.

Q5. What is the type of shipping and producing time ?

We offer EXW,FOB ,CIF ,DDU and DDP which you can choose as you like .

For the standard machine, the delivery time is 3-7 days after the payment.
For the non-standard machine, the delivery time is 7-15 days after the payment.
